Name: Eaton 9SX 6000i RT3U G2 230V UPS
Brand: Eaton Electric
SKU: 4923939
Price: 3326 EUR
Availability: InStock

Online double-conversion UPS with high efficiency for 230 V input
Multi-lingual graphic LC display with LED status bar,
Expansion slot for optional communication or network management card
USB and RJ232 ports,
Scalable with additional battery packs (EBMs),
Incl. tower stand and rack-mount kit

Input: 1-phase 230 V hardwire
Output: 8 x IEC320-C13, 3 x IEC320-C19

Please note: The UPS must be installed by a qualified electrician.

Eaton 9SX 6000i RT3U G2 230V UPS

Product
Product type	UPS for servers / network
Manufacturer’s warranty	2-year bring-in (see manufacturer's website for details)
Performance
Apparent power (VA)	6000 VA
Effective power	6000 W
Max. runtime (50% load)	7.0 min.
Max. runtime (70 % load)	5.0 min.
Max. runtime (100 % load)	2.0 min.
General
Technology	Double conversion (online)
Battery type	VRLA (lead acid)
Battery life	3 - 5 year(s)
Duration	Renewable
Network
SNMP / management	Optional
Physical properties
Chassis type	Tower / rack convertible
Rack units	3 U
Dimensions (W x H x D)	440 x 130 x 684 mm
Weight	43.1 kg
Version
Version	Europe
